How carbon monoxide binds to TiO2

~ moleculardreams ~ Leave a comment

What do a spacecraft, a breathalyzer, and carbon monoxide have in common? Nothing at all – you’d think. And you’d be wrong!  All three give you information on things that you cannot directly see, touch or measure. A spacecraft can capture some signal and send you beautiful images of a planet. With the help of a breath tester, a policeman may deduce the alcohol content in your blood. And using carbon monoxide, researchers may find highly reactive centers on materials surfaces.  Let’s focus on the latter and see how it works!

Left image: the Soyuz spacecraft (source: Wikimedia commons). Center image: a breathalyzer (source: photograpy by Elza Fiúza/ABr, distributed under a CC-BY 3.0 license). Right image: carbon monoxide (blue=carbon; red=oxygen).

When a molecule comes in contact with surface atoms, its properties change. By measuring these changes, you get information on the surface sites interacting with the molecule.  Molecular vibrations – that you can measure by infrared spectra – provide very useful information: the vibration of carbon monoxide is very sensitive to the type of surface sites.  That’s why this molecule is used to identify active centers on catalytic materials, such as titanium dioxide.

How does carbon monoxide (CO) bind to surface atoms?  If you’re a chemistry student, you (should) know very well how CO interacts with molecules and ions. You’ve learned that this molecule can work both as a donor and as an acceptor of electron density.  Well, what’s nice, is that this happens also on surfaces, and  you can see it experimentally.

Let’s see this step-by-step. Carbon monoxide is a peculiar molecule. When it acts as a donor, charge flows to its bonding partner, which could be, for example, a metal cation.  This process strengthens the C−O bond and increases its vibration frequency.  This means that, in the infrared spectrum of the sample, you’ll find the CO band at higher frequencies – “blue-shifted” – with respect to the free, unperturbed molecule.  But carbon monoxide can also accept electron density from its bonding partner. If this occurs, the C-O bond becomes weaker: its stretching frequency decreases, and you’ll see a “red-shifted” CO band in your spectrum.

Carbon monoxide is colorless, odorless, and highly toxic – a true and unmerciful silent killer. It binds to iron(II) in hemoglobin, and this prevents the delivery of oxygen to the human tissues. This is a – very unfortunate – case where carbon monoxide acts at the same time as a donor and as acceptor. The bond is synergic: CO donates to the metal,  the metal back-donates to CO, and these two mechanisms reinforce each other:– that’s why it kills.  This synergy  occurs in many molecular complexes of transition metals and ions – often with less dangerous consequences. It’s less known on metal oxide surfaces, but it may happen as well. Is this the case of TiO2?

Not apparently, because carbon monoxide can only be a donor towards Ti cations –  they are Lewis acids, and cannot give back electron density.  The lower is their coordination number, the stronger is their acid power.  For example, a Ti cation coordinated by 4 oxygens  – Ti(4) – should be a stronger acid than one bound to 5 oxygens  -Ti(5).

Researchers use carbon monoxide to explore the activity of surface cations and deduce their environment, in particular the number of oxygen neighbors. This information connects the reactivity of a catalytic center to its molecular structure,  and may help them to improve the catalyst.  Practically speaking, they send carbon monoxide on a TiO2 sample and measure the infrared spectrum.  The rule is simple: the higher the frequency of the CO band, the more reactive are the Ti sites on the sample, and the lower their coordination number.

sitetio2
The image shows a 5-coordinated  Ti center (left) and a 4-coordinated  Ti site (right) on  anatase-TiO2 surfaces

So if you had a TiO2 sample with Ti(5) sites, and a second one with Ti(4), what would you get from the experiment?  “The second sample should show a more blue-shifted CO band, because Ti(4) is a stronger Lewis acid”.  If you answered this, you’d be wrong… because we actually did the experiment, checked with calculations, and found the contrary.  We found that CO on Ti(4) gives a less blue-shifted band – even if Ti(4) is a stronger Lewis acid.  Just as if a breathalizer estimated a lower alcohol content in a drunker driver. This could happen only if a sort of magic potion neutralized the effects of alcohol (something similar exist in real life, but it’s a mineral and belongs to the large family of zeolites). Similarly, our carbon monoxide on Ti(4) should have received an antidote against the loss of electron density. The antidote could only be electron density: but where did it come from?  Simply from the oxygen atoms bound to Ti(4): they are close enough to CO and ready to help.

In short, what happens is that CO donates electron density to Ti, but the surface oxygens donate electron density to CO. The first process strenghtens the C-O bond, but the latter has opposite effects. As a result, you find the CO signal at frequencies lower than expected.  The two mechanisms are sketched in the figure below – my attempt to explain in a simple way the two-fold nature of the Ti-CO bond on titanium dioxide surfaces.

theTiCobond2

So, if you see high frequency bands in an infrared spectra of CO, please be warned: not necessarily they are due to very reactive sites on TiO2 surfaces.  And also keep in mind that carbon monoxide gives you indirect information on your sample.  Its signal can be influenced in complex ways by several factors – you might misinterpret your data, based on simple rules. From a practical viewpoint, i think that you should be aware of this, especially if you’re working on CO, or titanium dioxide materials. More speculatively, this story might help us to better understand how molecules interact with surface atoms. The complex, delicate balance of molecular-scale interactions is at the origin of technologically important phenomena – reactivity, catalysis, photocatalysis, just to mention some of them.  Understanding these interactions more deeply could help us to improve their practical applications. Much effort is still needed, but it’s worth doing!

This research by our group has been published recently (Deiana et.al., ChemPhysChem 2016, 17, 1956; 10.1002/cphc.201600284). It was also sketched in a short summary, and by an infographics in a previous post.  Here i used other words to tell the same story, because i feel it’s important to make research results accessible to a larger community.

My first computational chemistry lab

~ moleculardreams ~ Leave a comment

Teaching is an important part of my daily activity. It is time-consuming, requires a lot of energy and involves an emotionally intensive effort so, why not blogging about it?

Explaining  physical chemistry  to undergraduate students is by no means an easy task. Many students consider it too difficult -which is bad – and boring – which is even worse.  When last September i was asked to set up a new physical chemistry course from scratch, i went into panic mode. Mission impossible. How could i make this course interesting to students aspiring to become organic or analytical chemists?

Problem n. 1: The content. There were already several courses on theoretical chemistry. I wanted something different: with solid content, but new and appealing.  Two important topics were not sufficiently covered by other courses: electrostatics/electric currents, and intermolecular forces – quite useless and unexciting things, to students’ eyes. My idea was to show them that knowledge of those boring topics could unlock the door to molecular electronics and supramolecular chemistry. To make students willing to learn that stuff – quite an ambitious goal – I used examples, borrowed from the recent literature and even from my own research work.

Problem n. 2: The name.  Names of physical chemistry courses  often appear obscure and discouraging, to students. Fortunately I shared my worries with some colleagues, and, after some brainstorming, we converged on “applied physical chemistry: from molecules to devices”. Don’t know if this was a good choice – only time will tell. But all students of the master degree chose to follow it … because of the “applied”, i suspect. Anyway, that was a good start, at least.

Problem n. 3: The lab. That is, the practical part of the course. Why not a compchem lab? Despite being a computational chemist i never had the occasion of doing that before – i had to teach other courses  – and again i felt overwhelmed.  Many of the students had never seen any of the most basic Linux commands,  not even used a quantum chemistry code. Once again i shared my thoughts with colleagues, and looked through the web in search of suggestions. There’s a lot of excellent material, but, unfortunately, often too advanced for the needs of my students – most of them at their very first exposure to computational chemistry.

My solution was to schedule three 4-hour sessions. Very schematically, the objectives were the following:

1)  Learn the basic Linux commands, prepare  Gaussian-09 input files and run energy calculations for simple systems -a water molecule, a water molecule dimer, ethylene and benzene. Plot the electron density and the electrostatic potential surfaces and deduce from them the possible types of intermolecular interactions.

2) calculate by points the potential energy curve as a function of distance for a sodium cation interacting with a benzene molecule. Plot the curve and compare the resulting energy minimum distance with that obtained from a geometry optimization of the full system benzene-Na+.

3) (this was the most exciting part) – run energy calculations on components of molecular machines, e.g. small diazobenzene axles and crown ether rings, and try to discuss the possible intermolecular interactions between these components on the basis of the electrostatic potential maps. In the picture below, you can see the students actually doing such little exercise!

2016-06-09 10.56.40

I’m not sure that this was the right way to go. Of course, everything can be done better -some important issues, on e.g., accuracy and basis set choice, were necessarily swept under the carpet, but I had the feeling that the students sort of enjoyed their first approach to modeling.
